Alloy Steel Grease Injection Control Head with 10000psi Working Pressure and Hammer Union Connection for Wireline Operations

Min Bestellmenge : 1 Set Preis : USD 1-10000/set
Verpackung Informationen : Pollywood Lieferzeit : 30-50 Tage
Zahlungsbedingungen : L/c, t/t, d/p Versorgungsmaterial-Fähigkeit : 10 Set/Monat
Herkunftsort: CHINA Markenname: ZZ TOP OIL TOOLS
Zertifizierung: ISO, API Modellnummer: Fettinjektionskontrollkopf

Detailinformationen

Produkt: Fettinjektionskontrollkopf Material: Legierungsstahl
Arbeitsdruck: 10000psi Anwendung: Funkleitungsoperation
Verwendung: Drahtgebundene Druckregelgeräte Verbindung: Hammer Union
Arbeitstemp.: -29~121℃
Hervorheben:

10000psi Grease Injection Control Head

,

Hammer Union Grease Injection Control Head

,

Alloy Steel Wireline Pressure Control Equipment

Produkt-Beschreibung

Grease Injection Control Head Assembly with Stuffing box and Wireline Wiper

The Grease Injection Control Head is a sealing device designed for braided cable wireline operations, providing effective wireline sealing functionality. This essential component is used across various oil and gas well applications where pressure control is critical during wireline operations, particularly when fluid or gas loss cannot be tolerated.

Key Features
  • Positioned at the top of the pressure control equipment string
  • Combines Line Wiper Bell, Stuffing Box, Flow Tubes assembly, and ball check valve
  • Essential for maintaining well integrity during high-pressure operations
Technical Specifications
Wire Size Working Pressure Qty. Of Stuffing Box Qty. Of Flow Tubes Qty. Of Hydraulic Port Qty. Of Grease Injection Port Qty. Of Grease Return Port Service Working Temperature
7/32"
5/16"
15/32"
5000Psi 1 4 2 1 1 STD or H2S P+U -20°F~+250°℉
Or As Required
10000Psi 1 6 2 1 1
15000Psi 2 9 3 2 1
Alloy Steel Grease Injection Control Head with 10000psi Working Pressure and Hammer Union Connection for Wireline Operations 0
